What is the heating power of vacuum oil filter? How to save electricity?

The principle of vacuum oil filter dehydration is through negative pressure heating dehydration, how to heat needs to use heating pipe for heating.
Generally, the heating pipe of oil filter adopts 6kW / branch heating pipe. Generally speaking, a group of heating refers to the use of three 6kW heating pipes and 18kw, and then add the power of oil pump motor and vacuum pump motor, even if the total power of oil filter.

Generally, the flow rate of vacuum oil filter is 50L / min, and the flow rate below 50L / min is 1 group heating, and the flow rate above 50L / min is two groups of heating. Two groups of heating power of 36kw.

Therefore, it is not very accurate to judge the power consumption of the oil filter, because the heater will automatically stop heating when the oil is heated to a certain temperature, and the heating will be started automatically when the oil temperature is low, so as to effectively control the oil temperature and save power.

vacuum oil filter working principle
The oil enters the coarse filter element at the oil inlet, and then is heated by the heater. After vacuum filling, the oil-water separation is carried out under negative pressure, and the gas is evaporated and pumped away by a vacuum pump.

Vacuum oil filter is mainly composed of two parts
1. Impurity removal part, also known as: oil circuit part
2. Dehydration part, also known as: gas path part

Principle introduction:
The oil enters the coarse filter element at the oil inlet, and then is heated by the heater. After vacuum filling, oil-water separation is carried out under negative pressure. After evaporation, the gas is pumped out by vacuum pump. Under the cooling of condenser, water vapor turns into water droplets and is eliminated. In the vacuum tank, the oil is relatively heavy, which is extracted under the action of gear pump, filtered through the precision filter element, and then eliminated, and the impurities are intercepted on the filter element.
