SCM440 Heat Treatment Furnace

---

SCM440 is a commonly used steel grade for the production of high-strength fasteners. The product has the advantages of stable composition, low harmful elements, high steel purity, small decarburization layer, and few surface defects. It is easy to perform spheroidizing annealing and cold heading cracking during use. Low rate, stable heat treatment quality, uniform hardness, widely used in engines, molds and other industries.

1. SCM440 Features and Applications

It has the advantages of stable composition, low harmful elements, high purity of steel, small decarburized layer and few surface defects. Easy to spheroidize, low cold cracking rate. It is usually hardened and tempered. The ultimate tensile strength is 850-1000 Mpa. This material strikes a good balance between strength, toughness and wear resistance. The chromium content of the alloy provides good hardness permeability, and the molybdenum element imparts average hardness and high strength.

SCM440 reacts well in heat treatment and is easy to process under heat treatment conditions. This material provides many desirable characteristics, such as good strength and wear resistance, excellent toughness, good ductility and high temperature stress resistance, high strength and toughness, good hardenability, deep hardening, good welding performance, impact absorption Excellent performance, such as where the hammer head may rebound, almost no damage caused by impact.

2. SCM440 Chemical Composition

C	0.38-0.43
Si	0.15-0.35
Mn	0.60-0.85
P	≤0.03
S	≤0.03
Cu	≤0.30
Ni	≤0.25
Cr	0.90-1.20
MO	0.15-0.30
Ni	≤0.25
Cu	≤0.30

3. SCM440 Heat Treatment Furnace

Annealing 760±10℃ annealing, furnace cooling to 400℃ air cooling.

HB220-230

Normalize  860±10℃ normalize, air-cooled out of the furnace.

Quenching+tempering  840±10℃ quenched with water or oil (depending on the complexity of the product shape), tempered at 680-700 degrees. HB<217

Quenching+tempering  840±10℃ quenching oil, then 470℃ tempering treatment. HRC41-45

Quenching+tempering  840±10℃, quenching oil, and then tempering at 480°C. HRC35-45

Quenching+tempering  Quenching oil at 850°C, then tempering at 510°C. HRC38-42

Quenching+tempering  Quenching oil at 850°C, and then tempering at 500°C. HRC40-43

Quenching+tempering  Quenching oil at 850℃, then tempering at 510℃. HRC36-42

Quenching+tempering  Quenching oil at 850℃, then tempering at 560℃. HRC32-36

Quenching+tempering  Quenching oil at 860°C, then tempering at 390°C. HRC48-52 42CrMo round bar
