Characteristics of continuous aluminum brazing furnace

---

Continuous aluminum brazing furnace equipment, apply to under the condition of nitrogen protection, the use of corrosive soldering flux, continuous brazing automotive aluminum brazing, mainly composed of storage tank, solder spray drying, drying furnace, former room, brazing furnace, after the water cooling room, room, air cooling room, transmission and paragraphs of electrical control, air intake and exhaust pipes.

Continuous aluminum brazing furnace has the following characteristics:

1. The surface of the spray body is passivated, with beautiful appearance and good recovery effect of flux, which can effectively prevent the accumulation of flux in the spray room. It is also very convenient to clean up, and can effectively blow away the residual excess flux on the surface.

2, spray mixing system humanized design, flux recovery bucket is installed with impurities filter, the bucket is designed into a deep bucket structure, can effectively prevent flux due to mixing and overflow, and affect the appearance.

3. The slag cleaning room of the brazing furnace is equipped with a nitrogen preheating system. Because of the high temperature of the slag cleaning room, the flue gas waste heat recovery system can make full use of the waste heat of the flue gas to preheat the combustifying air, and the heat loss is small, which indirectly reduces the energy consumption lost by heating the nitrogen in the brazing furnace.

4. Energy-saving design, nitrogen loss is mainly in the feed port and the discharge port, the two sides of the furnace and the metal curtain are more closely connected, the metal curtain appears crimping after long-term use, blocking nitrogen overflow.

5, Automatic electrical control system, PLC intelligent control system preset manual and automatic two kinds of non-disturbing switching mode, can be ready to record the temperature curve of the area without error, the brazing furnace programmed control, can be very convenient to set the required heating time, to protect the furnace to make sharing. The touch screen can be used for real-time monitoring of faults of circuits, motors, temperature control and frequency converters, and timely detection and alarm.
