Automatic Vacuum Process Casting Equipment

---

1. Brief Description

Vacuum process casting molding machine is called vacuum sealing casting molding machine. It is a dry sand casting molding machine without adhesive. Based on the pressure generated by the vacuum pump, EVA film is used to form a vacuum sealing state. The dry sand is then tensioned and a mold is obtained. The quality of finished castings after pouring is very good. Our V-process casting machine has been rated as cleaner production catalogue for its high sand recovery rate, high material utilization rate and environmental protection advantages. At present, V process has been successfully applied to engineering machinery counterweight, petroleum machinery (including crank, reducer and counterweight), pulley, bolster, axle, brake drum, piano plane, manhole cover and high manganese steel lining plate.

2. Principle of Vacuum Casting Equipment

Electric control system 2 Film baking device 3 EVA mask 4 Negative pressure box and profile plate 5 Fixed vibration table 6 Vacuum hose 7 Negative pressure distribution tank 8 Vacuum pipe 9 Vacuum regulating tank 10 Water bath dedusting tank 11 Vacuum pump 12 Vacuum pump and water tank.

3. VRC Series Basic Vacuum (pressure) Casting Plant

Dimensions mm	Ultimate vacuum	Leakage rate Pa.L/S	Operating pressure	Metering mode	Mixing mode	Casting mode
Ф1800×2000	≤50Pa (unload)	≤100	≤0.4 MPa or none	Auto-metering by metering pump	Static mixing	Auto-control by computer
Ф2000×2200	≤50Pa (unload)	≤100	≤0.4 MPa or none	Auto-metering by metering pump	Static mixing	Auto-control by computer
Ф2200×2400	≤50Pa (unload)	≤100	≤0.4 MPa or none	Auto-metering by metering pump	Static mixing	Auto-control by computer
Ф2400×3000	≤50Pa (unload)	≤100	≤0.4 MPa or none	Auto-metering by metering pump	Static mixing	Auto-control by computer
Ф2500×3500	≤50Pa (unload)	≤100	≤0.4 MPa or none	Auto-metering by metering pump	Static mixing	Auto-control by computer
Ф3000×3500	≤50Pa (unload)	≤100	≤0.4 MPa or none	Auto-metering by metering pump	Static mixing	Auto-control by computer
Ф3200×3500	≤50Pa (unload)	≤100	≤0.4 MPa or none	Auto-metering by metering pump	Static mixing	Auto-control by computer
Ф3200×4000	≤50Pa (unload)	≤100	≤0.4 MPa or none	Auto-metering by metering pump	Static mixing	Auto-control by computer
