High Temperature Hydrogen Furnace

High Temperature Hydrogen Furnace Introduction
According to the temperature, hydrogen furnace is divided into 2 types of hydrogen Furnace :high temperature hydrogen furnace & medium temperature hydrogen furnace
According to the usage,furnace is divided into single-station hydrogen furnace & dual-station hydrogen furnace,
According to the structure ,furnace is divided into vertical hydrogen furnace, horizontal hydrogen furnace and bottom feed hydrogen furnace.
Among them, the high-temperature hydrogen furnace is used for powder metallurgy sintering, ceramic metallization process, reduction and sintering of phosphor powder, etc., while the medium-temperature hydrogen furnace is used for welding, annealing, degassing, degreasing, purification and other processes.
Users can propose the maximum temperature index of hydrogen furnace according to the process requirements.
The company with the capability of design, manufacturing, maintenance ,company mainly Design, production, maintenance and reconstruction for high temperature hydrogen furnace, medium temperature hydrogen furnace, single station hydrogen furnace, double station hydrogen furnace, bottom feeding hydrogen furnace, vacuum hydrogen dual-use furnace.

High Temperature Hydrogen Furnace Principle
Hydrogen sintering furnace is designed for the industrial production of hard alloy, dysprosium metal and ceramic materials by using tungsten, bile and other heating principles to realize sintering of carbide tool heads and various metal powder compacting bodies under protective atmosphere.
Tungsten sintering furnace is in the state of hydrogen protection after vacuum, the use of heating elements heating principle, through heat radiation conduction to the workpiece, suitable for scientific research, military industries.

High Temperature Hydrogen Furnace Main Structure And Composition
Structure:vertical, under the discharge mode.
Main constitute: Electric furnace body, vacuum system, water cooling system, pneumatic system, hydraulic system, feeding and discharging mechanism, base, work table, heating device (tungsten and molybdenum heating body and advanced insulation material), power supply device, electrical control system, etc.

High Temperature Hydrogen Furnace Technical Parameters
